| Freeze-drying area | 0.27㎡ |
| Installed power | 1kw |
| Number of shelves | 4+1layers |
| Shelf spacing | 32mm |
| Material tray size | 180*380*20mm |
| Shelf temperature | 0C~80℃ |
| Shelf thickness | 1mm |
| Cold trap | Lowest temperature -45℃ |
| Moisture capture capacity | 4kg |
| Cooling Method | Air cooler |
| Ultimate Vacuum | <10Pa(no load) |
| Heating method | Graphene heating |
| Vacuum Pump | customization |
| Compressor | Dongbei |
| Condenser | Jifeng |
| Machine weight | 94kg |
| Machine size | 660*660*550mm |
| Remark | Heating only |
| Remark | Heating only
|
| Chamber material | 8mm thick aluminum alloy tank, one‑step extruded special aluminum tube and seamless forging, seam-free, high strength, excellent sealing | |||
| Shape of chamber | cylindrical chamber | |||
| Chamber Door Material | Transparent acrylic, thickness 3cm | |||
| Chamber Sealing | Food-grade silicone rubber sealing | |||
| Method of lock | Snap lock | |||
| Opening direction | hinged on the right, opening to the left Opening angle ≥ 120° | |||
| The details of cold trap | ||||
| Cold trap material | Aluminium | |||
| Shape of cold trap | Round, multi-layer coil type coil | |||
| Shape of coil | Sprial style | |||
| Method of defrosting | Hot air defrosting, shelf heating + fan | |||
| Drain Valve | Manual valve/Electronic valve | |||
Freeze-drying area: 0.27 m²
Cold trap temperature: -40°C
Separator temperature: 0-80°C
Installed power: 1 kW
Processing capacity/batch: 3-4 kg
Water capture capacity: 4 kg
Number of separator layers: 4+1 layers
Separator spacing: 32 mm
Material tray size: 180 x 380 x 20 mm
Overall shape: Square integrated
Overall dimensions: 660 x 660 x 550 mm
Installed weight: 94 kg
Processing capacity: 3-4 kg
